VVVF Speed Double Drum Electric Winch Wire Rope Pulling Hoist Anchor Mooring Winch

HENAN SANTO CRANE CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap VVVF Speed Double Drum Electric Winch Wire Rope Pulling Hoist Anchor Mooring Winch from wholesalers

    Buy cheap VVVF Speed Double Drum Electric Winch Wire Rope Pulling Hoist Anchor Mooring Winch from wholesalers
    • Buy cheap VVVF Speed Double Drum Electric Winch Wire Rope Pulling Hoist Anchor Mooring Winch from wholesalers
    • Buy cheap VVVF Speed Double Drum Electric Winch Wire Rope Pulling Hoist Anchor Mooring Winch from wholesalers
    • Buy cheap VVVF Speed Double Drum Electric Winch Wire Rope Pulling Hoist Anchor Mooring Winch from wholesalers

    VVVF Speed Double Drum Electric Winch Wire Rope Pulling Hoist Anchor Mooring Winch

    Ask Lasest Price
    Brand Name : Santo
    Model Number : JM
    Price : 5000USD- 50000USD
    Payment Terms : L/C, D/A, T/T
    Supply Ability : 3500SETS/YEAR
    Delivery Time : 15~45 WORKING DAYS
    Certification : ISO
    • Product Details
    • Company Profile

    VVVF Speed Double Drum Electric Winch Wire Rope Pulling Hoist Anchor Mooring Winch


    Wire Rope Double Drum Electric Winch for Material Loading Unloading Hoisting Towing Pulling Mooring Anchor Winch Price




    Product Description:

    IN CONSTRUCTION, MINE, MARINE FIELDS, OUR WINCH IS BEST CHOICE FOR YOU.

    Towing, anchor, mooring, dredging, barge, dam gate winch and so on, we develop and produce winches for international customers, in most cases entirely tailored to their requirements.

    Electric winch is a kind of widely using machine in lifting machinery. It can lift heavy weight in the Construction Site and Port pier, also it can be the Tractive power in installing of the factories and mines.

    It not only can be used independently, but also can work with other largescale and complex machine. It has been a necessary machine in the Construction Site and Port pier.
    Electric winch is made up of motor, brake, drum, wire rope, electrical appliance, base ect , which can be customized according to client requirement.

    Parameter:


    ItemsRated load,
    KN
    Rated speed,
    m/min
    Rope capacity,
    m
    Rope diameter,
    mm
    MotorPowerSize,
    mm
    Weight,
    kg
    JM110151009.3Y112M-63620*701*417270
    JM1.6161615012.5Y132M2-65.5945*996*570500
    JM2201615013Y160M-67.5945*996*570550
    JM3.2329.515015.5YZR160M2-67.51430*1160*9101100
    JM3.2B321219515.5YZR160M2-67.51082*1014*610536
    JM5501027021.5YZR160L-6111235*1230*8051560
    JM5B509.520021.5YZR160L-6111620*1260*9451800
    JM5C509.525021.5YZR160L-6111235*1230*8051800
    JM5D501525021.5YZR180L-6151235*1230*8051850
    JM5E502025021.5YZR200L-6221235*1230*8052000
    JM6609.527024YZR180L-6151235*1230*8051800
    JM880825026YZR180L-6152090*1475*9562900
    JM8B809.535026YZR180L-6151075*1598*9852650

    Our electric winch characteristics:

    • Reasonable structure and design hoist
    • Easy to install and Maintenance
    • High efficiency and stable performance
    • Top quality with competitive and economic price
    • Speed: Dual Speed, VVVF Speed



    Our Services:

    As a professional Cranes & Lifting Solutions provider, we specialize in this field over 35 years, we Santo Crane has set up a perfect sales network and after-sales service system. We have 42 sales managers and 10 engineers especially for exporting business. We believe with our rich experience, we can provide you a professional solution supporting and satisfied service.

    Various special designs are available for use in particular conditions.
    This is one of our particular strengths. Together with our designers, we develop a customised solution with you for your special needs.

    After Order

    Iso 9001:2008 Certification Used Seimens Electric Hoist

    • Delievery Time: After signing the contract and recieving the depoist, the production will take 15~25 working days as per type of products. Special standard make cost 5~10 more working days.
    • Order Tracking: After the depoist recieved, there will be a professional team tracking the order from prodction to package and shipment.
    • Crane Testing: All the materials are purchased from high quality supplier in China or the world, beyond this, we also make commissioning and test before packagement to avoid the trouble back.

    After-sale Service

    Iso 9001:2008 Certification Used Seimens Electric Hoist

    • Warranty Period: We provide 12 month warranty for main body. Within 12 month, there is any quality problem with the main body(not including the wearing parts), we will arrange our professional engineers to provide repairment service. Also we will provide one group wearing parts for free.

    • Installation Service: If customer don't need our engineers for installation, we will provide Remote Advisory Services. Also we could arrange engineers to provide installation service if customer need.

    • Periodic follow up for cranes serving situation. Collecting customers comment, develop better products and service.

    • Any problems come out in the usage, if that because of the quality we will take full responibility, and arrange professional after-sale department to provide solution. if that because of the misoperation or other problems, we will also provide a professional technological supporting or arrange our engineers to help if customer need.
