European Style 50/10Ton Double Hook Overhead Bridge Crane For Factory

Ask Lasest Price
Brand Name :	SANTO
Model Number :	CXTD
Certification :	ISO, CE
Price :	USD8000-80000/set
Payment Terms :	L/C, T/T
Supply Ability :	2000set/year
Delivery Time :	30-45 working days

Add to Cart

Product Details
Company Profile

European Style 50/10Ton Double Hook Overhead Bridge Crane For Factory

European Style 60 Ton Double Hook Overhead Crane Bridge Crane For Factory Using

Specification:

Lifting Capacity	Span	Lifting Height	Work Duty	Main Hook Speed	Aux. Hook Speed	Trolley Traveling Speed	Crane Traveling Speed	Rail Track


t	m	m		m/min	m/min	m/min	m/min
5	13.5~19.5	18	A5	0.84~8.4		3.4~34	5.1~51	38kg
	22.5~31.5						5~50
5	13.5~19.5	18	A5	0.78~7.8		3~30	5~50	38kg
	22.5~31.5						5.2~52
16/5	13.5~19.5	18/18	A5	0.76~7.6	0.84~8.4	3.5~35	5.1~51	43kg
	22.5~31.5						5.2~52
20/5	13.5~19.5	18/18	A5	0.6~6	0.84~8.4	3.5~35	5.1~51	43kg
	22.5~31.5						5.2~52
32/5	13.5~19.5	18/18	A5	0.52~5.2	0.84~8.4	3.1~31	5.1~51	43kg
	22.5~31.5						5.2~52
50/10	13.5~19.5	18/18	A5	0.43~3.9	0.78~7.8	3.6~36	4.8~48	43kg
	22.5~31.5						5.4~54
Notes: Span, lifting height is customizable as requirements

Features:

1. Lightweight and Modular Design, Overall height is 20%~25% lower than traditional cranes;

2. Self-weight is lighter by 20%~30%;

3. Max wheel load reduces 15%~20%;

4. Smaller limiting size increases working scope;

5. Light structure reduces the cost of workshops;

6. Every component designed to be a standard series and interchangeable;

7. Modularization design is easy for transporting;

8. Standard modular design makes good quality and fast delivery.

Intelligent:

1. Electric anti-sway tech realize accurate positioning;

2. Advanced electric control tech turn it into a crane robot with semi-automatic control and full-automatic control;

Safety Protection:

Overload limiter, limit switch (lifting and travelling), interlocking protection device, buffer, rail clear plate, shield, bus protection plate, anti-collision device, main disconnecting switch, emergency brake system and motor overload protection device.

Company Information:

Santo crane mainly dealing in researching, developing and producing the lifting machinery, port machinery, construction-use tower crane, reducer, etc.
The leading products of Santo widely used in Machinery, Metallurgy, Electric Power, Railway, Aerospace , Port, Petroleum, Petrochemical, etc, our products are serving the national key projects such as: the South-to-North Water Transfer Project, the West-East National Gas Transmission, the Three Gorges Hydropower Station, Jiuquan Satellite Lunching Center, Qinshan Nuclear Power Station, Hangzhou Bay Bridge, Beijing Olympic Games and so on, accelerate successfully the launch of Spacecraft Shenzhou-10 and Chang’e-3,our products have been exported to more than 69 countries like America, Japan, Russia, Korea, etc. In 2013 the annual sales revenue reached 6.669 billion, and the Overhead Traveling Crane and the Gantry Crane continue to hold the first position around the whole country
